Models: CHSRTMCC400_DC_1500V_R
Input Voltage: 1000-1800 VDC
Traction Rated Output: 360 kW(@wheel)
Dimensions: 2500×1760×470 mm
Traction Control System
Our traction control systems are at the heart of modern railway propulsion. We offer a range of components including traction motors, control consoles, and electrical cabinets that work together to optimize power distribution and control. These systems are designed to provide precise control over acceleration, speed, and braking, ensuring smooth and efficient train operation. Our traction control systems are compatible with various types of railway vehicles, making them a versatile solution for different applications.
Regardless of the type of device, RailMac provides reliable and stable support for your business growth.
Advantages of RailMac Traction Control System
The traction control systems we provide offer several key advantages. They are designed to deliver high performance, with advanced control algorithms that ensure smooth and efficient operation. The systems are also highly reliable, with robust components that are built to withstand the demands of daily use. By choosing our traction control systems, you can benefit from enhanced safety and efficiency, as well as reduced maintenance costs. Our systems are also designed to be easily integrated with existing railway infrastructure, making them a practical and cost-effective solution for modernizing your fleet.
Vehicle Auxiliary Power System-Video-DB2/3 | CR300BF/CR400BF
Vehicle Auxiliary Power System-Video-DB2/3 wiper device is CR300BF, CR400BF standard EMU supporting product produced for CRRC Tangshan Company and Changke Corporation. The wiper system is composed of the following components: a drive device, a scraper arm, a scraper frame, a scraper, a pump, a liquid level display switch, a junction box and a wiper switch. Among them, the core component of the wiper motor has been implemented domestically.
Tourist Train
The CRRC Zhuzhou 1435 series dual rail sightseeing car inherits the technological DNA of CRRC high-speed rail and is designed for in-depth sightseeing in scenic areas. The innovative double-decker structure features a panoramic window on the first floor for comfortable all-weather sightseeing and an open-top layout on the second floor for a 360° immersive natural experience.
Traction System
CHSR's CHSR™ CC750 air-cooled converter is a highly integrated traction and auxiliary "two-in-one" core equipment. It condenses key power conversion functions into a single compact enclosure, providing robust and stable power for intercity trains through standardized modular design, intelligent air cooling (IP65 protection), and mature and reliable components.
Bogie and Braking System
CRRC Braking Systems Co., Ltd.'s disc brake calipers use hydraulic or pneumatic-hydraulic conversion drive technology.They integrate automatic gap adjustment, modular caliper body, and three-point floating suspension design to ensure precise contact between brake pads and discs.
Track Body Components
RailMac provides railway solutions, focusing on one-stop Lince/Huanji wiper services (R&D, production, maintenance) plus rail air conditioning. It offers diverse wipers (DC110V/74V/24V, pneumatic) and developed China’s first IP-owned CRH3 EMU wiper, with products batch-loaded in CRH380/CR400BF/CR300BF.
Maintenance Equipment
RunWell is a high-tech enterprise specializing in the fields of rail transit and military industry. Its car lift machine products integrate German drive technology (such as the Demag three-in-one modular system) with intelligent control, supporting heavy-duty conditions of over 150 tons.
Railway Components
CRRC specializes in innovative environmental protection sanitation systems. Products like vacuum water - saving toilet modules and waterless ecological toilets, made in an orderly factory, are applied in railways, public facilities, and outdoor scenarios.
RailMac
Partnering with global leaders, RailMac offers superior railway equipment and solutions at competitive prices. It hit milestones like Thailand’s 2017 first local train, pioneered SEA new energy trains, and joined Russia’s high-speed rail project, boosting its railway industry presence.
Find Traction Control System by Series
This is the list of all series of RailMac Traction Control System.
Click here to find traction control system by type.
Train Traction System
Models: CHSRTMCC200_DC_750V_R Models: CHSRTMGJ-Tac&Aux Models: CHSRMGK-DJ-Tac&Aux Models: CHSRTMCC400_DC_750V_R_B Models: CHSRTMCC400_DC_750V_R_A Models: CHSRTMCC1500_DE_1500V_M Models: CHSR™CC750_DE_3000V_U(Contact grid power supply,Internal combustion power pack power supply) Model Codes: CHSRTMCC750_DC_1500V_U_A/CHSRTMM280_DC_1500V_U_A Models:CHSRTMCC750_MS_25kV-1500V_U Model Codes: CHSRTMCC750_DC_1500V_U_B (Traction) Model Code: CHSRTMCC750_DC_1500V_U_T01 RailMac CHSR™CC200 Water Cooling Converter
Input Voltage: 500-900 VDC
Traction Rated Output: 2 × 120 kW (@ wheel)
Dimensions: 800×1800×460 mm RailMac CHSR™GJ-Tac&Aux Air-cooled Converter (URT)
Input Voltage: contact grid 1000-1800 VDC
Traction Rated Output: contact grid 400 kW (@ wheel); Battery powered 300 kW (@ wheel)
Dimensions: 3768 × 2004 × 608 mm RailMac CHSR™GK-DJ-Tac&Aux Water Cooling Converter(FMR)
Input Voltage: Battery 620 VDC
Traction Rated Output: Battery power supply 400 ~ 800 kW (@ wheel)
Dimensions: Design based on customer’s actual interface requirements RailMac CHSR™CC400(750VDC) Air-cooled Converter
Input Voltage: 500 – 900 VDC
Traction Rated Output: 2 × 120 kW(@wheel)
Dimensions: 1600 × 1700 × 452 mm RailMac CHSR™CC400 Water Cooling Converter
Input Voltage: 500-900 VDC or internal combustion power pack power
Traction Rated Output: 2 × 200 kW (@wheel)
Dimensions: 1600 × 1940 × 455 mm RailMac CHSR™CC1500 Water Cooling Converter
Input Voltage: Internal combustion engine power supply
Traction Rated Output: 3 × 378 kW (@wheel)
Dimensions: 850 × 1350 × 1910 mm RailMac CHSR™CC750 Air-cooled Converter (Intercity railway)
Input Voltage: 3000 VDC
Traction Rated Output: 2×600 kW(@ wheel)
Dimensions: 3280 × 2000 × 660 mm RailMac Water Cooling Converter (Metro)
Input Voltage: 1000 -1800 VDC
Traction Rated Output: 950 kW
Dimensions: 2000 × 2100 × 680 mm RailMac Water Cooling Converter (Intercity railway)
Input Voltage:25000 VAC/1500 VD (Two types of input current system)
Traction Rated Output:2×600 kW(@wheel)
Dimensions:3070 × 2130 × 635 mm (Traction and Auxiliary Integration) RailMac Air-cooled Converter (Metro)
Input Voltage: 500-1800 VDC
Traction Rated Output: 950 kW (@wheel)
Dimensions: 2200 × 1530 × 600 mm (traction box),2200 × 2060 × 600 mm (auxiliary box) RailMac Permanent Magnet Traction Converter
Input Voltage Range: 1000-1800 VDC
Traction Rated Power: 1100 kW
Dimensions: 2777 × 2035 × 745 mm
Train Battery
Battery Pack Rated Voltage: 789.6 V Battery Pack Rated Voltage: 423 V Battery Pack Rated Voltage: 103.5 V Battery Pack Rated Voltage: 103.5 V Battery Pack Rated Voltage: 469 V RailMac Metro Engineering Vehicle Power System
Voltage Range: 652 ~ 900 V
Rated Capacity: 157.9 kWh/box
Maximum Output Power: 200 kW/box
Cooling Method: Natural heat dissipation RailMac Light Rail Transit Power System
Voltage Range: 360 ~ 477 V
Rated Capacity: 42.3 kWh/box
Continuous Output Power: 125 kW/box
Cooling Method: Natural heat dissipation RailMac Vehicle Emergency Self-Traction Power System
Voltage Range: 77 ~ 124 V
Rated Capacity: 32.6 kWh / Box
Continuous Output Power: 160 kW / Box
Cooling Method: Natural heat dissipation RailMac Vehicle Auxiliary Power System
Voltage Range: 77 ~ 124 V
Rated Capacity: 32.6 kWh / Box
Continuous Output Power: 160 kW / Box
Cooling Method: Natural heat dissipation RailMac On-board Self-contained Auxiliary Power Supply System
Voltage Range: 320 ~ 540 V
Rated Capacity: 56 kWh/box
Continuous Output Power: 140 kW/box
Cooling Method: Natural heat dissipation
Traction Motor
Rated/Peak Power: 250/360 kW Rated/Peak Power: 250/410 kW Rated/Peak Power: 100/200 kW Rated/Peak Power: 200/260 kW Rated/Peak Power: 160/270 kW Rated/Peak Power: 115/180 kW Rated/Peak Power: 100/150 kW Rated/Peak Power: 120/240 kW Rated/Peak Power: 60/120 kW Rated/Peak Power: 70/145 kW Rated/Peak Power: 32.5/70 kW Rated/Peak Power: 60/80 kW Rated/Peak Power: 60/130 kW Rated/Peak Power: 20/40 kW Rated/Peak Power: 40/75 kW Rated/Peak Power: 30/60 kW Rated/Peak Power: 60/120 kW RailMac TZ400XS015B
Rated/Peak Torque: 1600/2500 Nm
Motor Weight: 298 kg
Motor Size: Φ 453×524 mm
Rated/Max. RPM: 1500/3500 rpm RailMac TZ400XS013A
Rated/Peak Torque: 1750/2800 Nm
Motor Weight: 328 kg
Motor Size: Φ 451×576 mm
Rated/Max. RPM: 1364/3500 rpm RailMac TZ400XS010A
Rated/Peak Torque: 1061/2500 Nm
Motor Weight: 246 kg
Motor Size: Φ 440×371 mm
Rated/Max. RPM: 900/2400 rpm RailMac TZ400XS009A
Rated/Peak Torque: 1140/3000 Nm
Motor Weight: 260 kg
Motor Size: Φ 440×371 mm
Rated/Max. RPM: 1675/3300 rpm RailMac TZ380XS029B
Rated/Peak Torque: 750/1310 Nm
Motor Weight: 180 kg
Motor Size: Φ 434×268 mm
Rated/Max. RPM: 2038/5000 rpm RailMac TZ380XS027C
Rated/Peak Torque: 550/1200 Nm
Motor Weight: 135 kg
Motor Size: Φ 434×268 mm
Rated/Max. RPM: 2000/4000 rpm RailMac TZ380XS027B
Rated/Peak Torque: 500/1000 Nm
Motor Weight: 135 kg
Motor Size: Φ 434×268 mm
Rated/Max. RPM: 1910/3500 rpm RailMac TZ380XS016L
Rated/Peak Torque: 1200/2800 Nm
Motor Weight: 222 kg
Motor Size: Φ 434×380 mm
Rated/Max. RPM: 955/3000 rpm RailMac TZ220XS028A
Rated/Peak Torque: 150/325 Nm
Motor Weight: 55 kg
Motor Size: Φ 278×274.5 mm
Rated/Max. RPM: 3820/12000 rpm RailMac TZ220XS026A
Rated/Peak Torque: 150/330 Nm
Motor Weight: 65.5 kg
Motor Size: Φ 278×274 mm
Rated/Max. RPM: 4450/12000 rpm RailMac TZ220XS020A
Rated/Peak Torque: 225/450 Nm
Motor Weight: 69 kg
Motor Size: Φ 260×342 mm
Rated/Max. RPM: 2860/6500 rpm RailMac TZ220XS017A
Rated/Peak Torque: 360/560 Nm
Motor Weight: 96 kg
Motor Size: Φ 367×412 mm
Rated/Max. RPM: 1600/2400 rpm RailMac TZ220XS013A
Rated/Peak Torque: 140/320 Nm
Motor Weight: 46.7 kg
Motor Size: Φ 270×222.5 mm
Rated/Max. RPM: 4000/12000 rpm RailMac TZ180XS017A
Rated/Peak Torque: 150/300 Nm
Motor Weight: 46 kg
Motor Size: Φ220×298 mm
Rated/Max. RPM: 1273/2400 rpm RailMac TZ180XS014E
Rated/Peak Torque: 48/130 Nm
Motor Weight: 27 kg
Motor Size: Φ 236 × 207 mm
Rated/Max. RPM: 8100/12000 rpm RailMac TZ180XS009-B
Rated/Peak Torque: 100/225 Nm
Motor Weight: 38 kg
Motor Size: Φ 220×294 mm
Rated/Max. RPM: 2865/9000 rpm RailMac TZ180XS009-A
Rated/Peak Torque: 120/200 Nm
Motor Weight: 38 kg
Motor Size: Φ 220×294 mm
Rated/Max. RPM: 4775/7500 rpm
Train Converter
Products Not Available
The relevant products still under developing or waiting to be update, please contact our sales team for latest updates.
Train Control Console
Products Not Available
The relevant products still under developing or waiting to be update, please contact our sales team for latest updates.
Train Electrical Cabinet
Products Not Available
The relevant products still under developing or waiting to be update, please contact our sales team for latest updates.
