RailMac Air-cooled Converter (Metro)

The CHSR™ CC750 air-cooled converter (metro application) is a high-performance core device specifically designed for metro systems by Guangzhou Shentie Traction. Its compact, lightweight design and flexible adaptability meet the high-efficiency and reliable operation requirements of urban rail transit. The product features a highly integrated design, combining the reactor and transformer to save installation space. It offers integrated or separate main and auxiliary power supply solutions, adaptable to various power supply systems and vehicle/rack control methods. The cooling system uses forced air cooling, balancing heat dissipation and ease of maintenance. The traction rated output reaches 950kW (wheel circumference), auxiliary output is 3×400V/50Hz/280kVA, and charger output is 110VDC/25kW. It is designed for undercarriage mounting to suit metro layouts. This product has been applied in key metro projects in Beijing, Tianjin, Guangzhou, and other cities, making it a trusted choice in the urban rail transit sector.

Features of Air-cooled Converter (Metro)

  • Compact, lightweight.

  • Integration of all reactor and transformer equipment, reducing the number of equipment boxes and system weight.

  • Integrated traction and auxiliary, or separate traction and auxiliary .

  • Suitable for DC, AC, internal combustion and other power supply systems, as well as vehicle control, frame control and other control modes.

Air-cooled Converter (Metro) Technical Parameter Table

Model Codes:CHSRTMCC750_DC_1500V_U_B (Traction)
CHSRTMM280_DC_1500V_U_B (Auxiliary)
Input Voltage:500~1000 VDC, 1000~1800 VDC
Traction Rated Output:950 kW (@wheel)
Auxiliary Rated Output:3 × 400V / 50 Hz / 280 kVA
Battery Charger:110VDC / 25 kW
Mounting:Under mounting
Cooling:Forced air-cooling
Dimensions (L x W x H):2200 × 1530 × 600 mm (traction box)
2200 × 2060 × 600 mm (auxiliary box)
