RailMac CHSR™GJ-Tac&Aux Air-cooled Converter (URT)
The CHSR™GJ-Tac&Aux Air-cooled Converter is a high-reliability power solution exclusively designed for Urban Rail Transit (URT) systems. It features dual input compatibility, supporting both 1000~1800 VDC contact grid power and 750 VDC battery power to adapt to diverse operational scenarios. For traction performance, it delivers 400 kW (@wheel) under contact grid supply and 300 kW (@wheel) with battery power, ensuring robust and consistent motive force for URT vehicles.
Its auxiliary system provides stable 3×400 V/50 Hz power with 80 kVA capacity, fully satisfying the electricity needs of on-board equipment. Equipped with a 24 VDC/6.5 kW battery charger, the converter adopts undercarriage mounting for space-efficient integration and forced air cooling for efficient heat dissipation, guaranteeing reliable operation even in high-frequency urban rail working conditions. With dimensions of 3768×2004×608 mm, it balances performance and installation adaptability, making it a trusted choice for URT applications.
Features of CHSR™GJ-Tac&Aux Air-cooled Converter (URT)
Equipped with urban rail transit locomotives.
Traction assist integrated design, compact structure.
Efficient water cooling system.
It can be applied to catenary or third rail power supply and battery power supply two working modes.
The design power can meet the various operations of urban rail transit locomotives in the depot yard and the main line.
CHSR™GJ-Tac&Aux Air-cooled Converter (URT) technical parameter table
| Models: | CHSRTMGJ-Tac&Aux |
| Input voltage: | contact grid 1000-1800 VDC; Battery DC750V |
| Traction rated output: | contact grid 400 kW (@ wheel); Battery powered 300 kW (@ wheel) |
| Auxiliary rated output: | 3 × 400V / 50 Hz/80 kVA |
| Battery charger: | 24VDC/6.5 kW |
| Mounting: | Under mounting |
| Cooling: | Forced air-cooling |
| Dimensions (L × W × H): | 3768 × 2004 × 608 mm |
