RailMac CHSR™CC400(750VDC) Air-cooled Converter
The CHSR™CC400(750VDC) Air-cooled Converter (model: CHSRTMCC400_DC_750V_R_B) is a compact, high-efficiency power conversion unit engineered for rail transit applications. It operates on a 500~900 VDC input voltage, delivering a traction rated output of 2×120 kW (@wheel) to support stable vehicle operation. Its auxiliary system supplies reliable 3×400 V/50 Hz power with 45 kVA capacity, catering to the electricity needs of on-board equipment.
Equipped with a flexible battery charger (24 VDC/12 kW or 36/72/110 VDC/19 kW options), the converter adopts roof mounting to save undercarriage space and forced air cooling for efficient heat dissipation. With compact dimensions of 1600×1700×452 mm, it boasts strong adaptability to limited-space rail vehicle configurations.
Features of CHSR™CC400(750VDC) Air-cooled Converter
Designed for light rail and monorail vehicle applications.
DC 750V and DC 1500V power supply systems.
Integrated traction and auxiliary, or separate traction and auxiliary.
Battery charger with silicon carbide semiconductor.
Small size and light weight of the whole converter.
CHSR™CC400(750VDC) Air-cooled Converter technical parameter table
| Models: | CHSRTMCC400_DC_750V_R_B |
| Input voltage: | 500~900 VDC |
| Traction rated output: | 2 × 120kW(@wheel) |
| Auxiliary rated output: | 3 × 400V/ 50 Hz /45 kVA |
| Battery charger: | 24 Vdc/12 kW or 36/72/110Vdc/19kW |
| Mounting: | Roof Mounting |
| Cooling: | Forced air-cooling |
| Dimensions (L × W × H): | 1600 × 1700 × 452 mm |
