RailMac CHSR™CC400(1500VDC) Air-cooled Converter
The CHSR™CC400(1500VDC) Air-cooled Converter (model: CHSRTMCC400_DC_1500V_R) is a high-reliability power conversion unit engineered for rail transit applications. It operates on a 1000~1800 VDC input voltage, delivering a stable traction rated output of 360 kW (@wheel) to support robust vehicle operation. Its auxiliary system supplies consistent 3×400 V/50 Hz power with 45 kVA capacity, fully meeting the electricity demands of on-board equipment.
Equipped with a flexible battery charger (24 VDC/12 kW or 36/72/110 VDC/19 kW options), the converter adopts roof mounting for space-efficient integration, optimizing undercarriage layout for rail vehicles. The forced air-cooling system ensures efficient heat dissipation, guaranteeing reliable performance under high-load and frequent-start operating conditions. With compact dimensions of 2500×1760×470 mm, it boasts strong adaptability to limited-space rail configurations, making it an ideal power solution for 1500VDC-rated rail transit scenarios.
Features of CHSR™CC400(1500VDC) Air-cooled Converter
Designed for light rail and monorail vehicle applications.
DC 750V and DC 1500V power supply systems.
Integrated traction and auxiliary, or separate traction and auxiliary.
Battery charger with silicon carbide semiconductor.
mall size and light weight of the whole converter.
CHSR™CC400(1500VDC) Air-cooled Converter technical parameter table
| Models: | CHSRTMCC400_DC_1500V_R |
| Input voltage: | 1000~1800VDC |
| Traction rated output: | 360kW(@wheel) |
| Auxiliary rated output: | 3 × 400 V/ 50 Hz /45 kVA |
| Battery charger: | 24Vdc/12 kW or 36/72/110Vdc/19kW |
| Mounting: | Roof Mounting |
| Cooling: | Forced air-cooling |
| Dimensions (L × W × H): | 2500 × 1760 × 470 mm |
