RailMac Water Cooling Converter (Metro)
This metro – dedicated water – cooled converter system includes two core units: traction converter CHSRTMCC750_DC_1500V_U_A and auxiliary converter CHSRTMM280_DC_1500V_U_A, with an input voltage range of 1000~1800 VDC. The traction unit delivers a rated output of 950 kW at the wheel, while the auxiliary unit supplies 3 – channel 400V/50 Hz power with 280 kVA capacity. It also integrates an 110VDC/25 kW battery charger. Designed for undercarriage mounting, the traction and auxiliary boxes feature compact dimensions (2000×2100×680 mm and 2000×2065×680 mm respectively), ensuring efficient heat dissipation and reliable operation for metro vehicles.
Features of Water Cooling Converter (Metro)
Water Cooling converters combine modularity, efficient cooling and high reliability.
Suitable for metro and intercity rail vehicle applications.
Integrated traction and auxiliary or separate traction and auxiliary design.
Suitable for DC, AC, internal combustion and other power supply system, as well as vehicle control, frame control and other control modes.
Water Cooling Converter (Metro) technical parameter table
| Model Codes: | CHSRTMCC750_DC_1500V_U_A (Traction) CHSRTMM280_DC_1500V_U_A (Auxiliary) |
| Input Voltage: | 1000-1800 VDC |
| Traction rated output: | 950 kW (@ wheel) |
| Auxiliary rated output: | 3 × 400V/ 50 Hz /280 kVA |
| Battery charger: | 110VDC/25 kW |
| Mounting: | Under mounting (undercarriage) |
| Cooling: | Water cooling |
| Dimensions (L × W × H): | 2000 × 2100 × 680 mm (traction box) 2000 × 2065 × 680 mm (auxiliary box) |
