RailMac Shielded Standard Wall Thickness Multi-Core Cable

EN50264 specifies electrical, control, and related wiring cables for internal and external protective devices in railway vehicles with low-smoke, halogen-free, and anodic properties. These cables are used for control, auxiliary, and main circuit wiring, such as cable harnesses, video surveillance systems, platform screen doors, seat control systems, and traffic communication systems. They are suitable for EMU (Electric Multiple Unit)/DMU (Diesel Multiple Unit) trains, light rail, sidings, and metro trains.

Advantages of EN50264-2-2 300V/500V MMS

  • Used as power and control cables when installed inside or outside railway locomotives, where handling and installation costs are a significant factor to consider.

  • Used for control, auxiliary, and main circuit wiring such as cable TV suspenders, switches and control panels, driver’s cabs, etc.

Technical Specifications

Model:EN50264-2-2 300V/500V MMS
Temperature Resistance:-40~90°C
Rated Voltage:300/500V
Fire Resistance Rating:HL3 compliant with EN45545-2 R15/R16
Insulation Strength:>10 MPa
Elongation at Break:>125%
Cable Bending Radius:6D (D: Cable Outer Diameter)
Color:Black

coming soon

coming soon

coming soon

Number of cores and nominal
cross-section
Conductor Diameter d
Average insulation
thickness
Core Outer DiameterAverage Sheath ThicknessCable Outer Diameter DConductor Resistance at
20°C
Insulation Resistance at
20°C

Reference Weight

Heat of Combustion

n × mm²Min. mmmmMin. mmMax. mmmmMin. mmMax. mmMax. Ω/kmNon-oil-resistant
Min. MΩ·km
Oil-resistant
Min. MΩ·km
kg/kmMJ/km
2*11.250.62.42.80.161.48.19.5201407094
3*11.250.62.42.80.161.48.39.82014070112
4*11.250.62.42.80.161.4910.62014070131
5*11.250.62.42.80.161.49.711.22014070155
6*11.250.62.42.80.161.41011.52014070177
7*11.250.62.42.80.161.410.412.22014070185
8*11.250.62.42.80.161.411.312.22014070215
9*11.250.62.42.80.211.412.514.62014070239
10*11.250.62.42.80.211.412.814.92014070261
11*11.250.62.42.80.211.413.315.62014070284
12*11.250.62.42.80.211.413.315.62014070302
13*11.250.62.42.80.211.413.916.52014070319
14*11.250.62.42.80.211.413.916.52014070332
15*11.250.62.42.80.211.414.917.22014070353
16*11.250.62.42.80.211.414.917.22014070370
17*11.250.62.42.80.211.415.718.42014070388
18*11.250.62.42.80.211.415.718.42014070406
19*11.250.62.42.80.261.415.718.42014070423
20*11.250.62.42.80.261.416.1192014070447
21*11.250.62.42.80.261.416.419.22014070463
22*11.250.62.42.80.261.417.820.52014070487
23*11.250.62.42.80.261.418.121.22014070515
24*11.250.62.42.80.261.518.121.22014070538
25*11.250.62.42.80.261.618.521.82014070567
26*11.250.62.42.80.261.618.521.82014070583
27*11.250.62.42.80.261.618.521.82014070597
28*11.250.62.42.80.261.619.122.82014070619
——END——

Note: All Above Data are Just for Reference, All Data Might Change Without Notices or Updates, Please Contact Our Sales Team to Confirm All Details Via WhatsApp or Email.
