RailMac CR300 Fairing

The CR300 Fairing is a core end-connection component adapted to the CR300 series EMU trains, undertaking key functions such as train sealing, safety protection, and environmental adaptability. Its design strictly matches the CR300 series’ 250km/h operating speed requirements. Through precise structural parameter optimization and high-standard performance design, it becomes an important component ensuring the safe and comfortable operation of the train, combining reliability with the advantages of domestically produced technology.

Advantages of CR300 Fairing

  • Precise structural dimensions and strong adaptability: The end-wall spacing is set at 650mm, meeting the spatial layout requirements for EMU end connections and ensuring a perfect fit with the car body structure. It also provides reasonable space for end-wall sealing and wiring, improving overall assembly compatibility.

  • Excellent curve-passing performance: Supports complex track conditions such as “R180m curve + 10m transition straight line + R180m curve,” ensuring flexible train steering even in mountainous or curve-heavy sections, reducing stress concentration at the end of the car, and further enhancing ride stability in conjunction with the bogie design.

  • Leading flame-retardant safety standards: Strictly adhering to Q/CR699-2019 “Technical Conditions for Flame Retardant Materials of Non-metallic Materials for Railway Passenger Cars,” the materials have passed multiple tests including flame retardancy, low smoke, non-toxic (low toxic), and halogen-free. In fire scenarios, it can effectively delay flame spread, reduce smoke and toxic gas generation, and maximize passenger safety.

  • Combining adaptability and reliability: Based on the CR300 series platform design, the components are highly interchangeable and easy to maintain and replace. At the same time, after long-term line verification, it can work stably under different terrain and climate conditions, helping to reduce the total life cycle cost.

Technical Specifications

Distance Between End Walls:650mm
Curve Passing Ability:Curve R180m +transition straight line 10m + curve R180m.
Fire Performance:Fire performance should be in accordance with Q/CR699-2019

coming soon

coming soon

coming soon

Vehicle Auxiliary Power System-Video-DB2/3 | CR300BF/CR400BF

Vehicle Auxiliary Power System-Video-DB2/3 wiper device is CR300BF, CR400BF standard EMU supporting product produced for CRRC Tangshan Company and Changke Corporation. The wiper system is composed of the following components: a drive device, a scraper arm, a scraper frame, a scraper, a pump, a liquid level display switch, a junction box and a wiper switch. Among them, the core component of the wiper motor has been implemented domestically.

FIND MORE

Tourist Train

The CRRC Zhuzhou 1435 series dual rail sightseeing car inherits the technological DNA of CRRC high-speed rail and is designed for in-depth sightseeing in scenic areas. The innovative double-decker structure features a panoramic window on the first floor for comfortable all-weather sightseeing and an open-top layout on the second floor for a 360° immersive natural experience.

FIND MORE

Traction System

CHSR's CHSR™ CC750 air-cooled converter is a highly integrated traction and auxiliary "two-in-one" core equipment. It condenses key power conversion functions into a single compact enclosure, providing robust and stable power for intercity trains through standardized modular design, intelligent air cooling (IP65 protection), and mature and reliable components.

FIND MORE

Bogie and Braking System

CRRC Braking Systems Co., Ltd.'s disc brake calipers use hydraulic or pneumatic-hydraulic conversion drive technology.They integrate automatic gap adjustment, modular caliper body, and three-point floating suspension design to ensure precise contact between brake pads and discs.

FIND MORE

Track Body Components

RailMac provides railway solutions, focusing on one-stop Lince/Huanji wiper services (R&D, production, maintenance) plus rail air conditioning. It offers diverse wipers (DC110V/74V/24V, pneumatic) and developed China’s first IP-owned CRH3 EMU wiper, with products batch-loaded in CRH380/CR400BF/CR300BF.

FIND MORE

Maintenance Equipment

RunWell is a high-tech enterprise specializing in the fields of rail transit and military industry. Its car lift machine products integrate German drive technology (such as the Demag three-in-one modular system) with intelligent control, supporting heavy-duty conditions of over 150 tons.

FIND MORE

Railway Components

CRRC specializes in innovative environmental protection sanitation systems. Products like vacuum water - saving toilet modules and waterless ecological toilets, made in an orderly factory, are applied in railways, public facilities, and outdoor scenarios.

FIND MORE

RailMac

Partnering with global leaders, RailMac offers superior railway equipment and solutions at competitive prices. It hit milestones like Thailand’s 2017 first local train, pioneered SEA new energy trains, and joined Russia’s high-speed rail project, boosting its railway industry presence.

FIND MORE

Model

Distance Between End Walls

Curve Passing Ability

CR300 Fairing650 mmCurve R180 m
CR200 Gangway800 mmCurve R145 m
CR200 Fairing800 mmCurve R145 m
Type B Subway Windshield520 – 700 mmR110 – R150 m
Type A Subway Windshield780–920 mmR140 – R150 m
CR300 Gangway650 mmCurve R180 m
CR400BF Fairing650 mmCurve R180 m
CR400BF Gangway650 mmCurve R180 m
——END——

Product Name

Vehicle Model

Type of Sidewall

Distance of the end of car

Curve

Sound Insulation

Fire Protection

GangwayCR400BF/650mmR180m、R180m-10m-R180m38dBQ/CR699
GangwayCRH5/880mmR145m、R145m-10m-R145m38dBDIN55510
GangwayCRH3A/650mmR180m、R180m-10m-R180m38dBQ/CR699
FairingCR400BF/650mmR180m、R180m-10m-R180m/Q/CR699
GangwayCRH3A/650mmR180m、R180m-10m-R180m38dBQ/CR699
FairingCRH3A/650mmR180m、R180m-10m-R180m/Q/CR699
GangwayCRH3/850mmR180m、R180m-10m-R180m38dBDIN55510
GangwayCRH3/850mmR180m、R180m-10m-R180m38dBDIN55510
GangwayCRH6one piece of side wallBelow500mm side wall 700mmR180m、R180m-10m-R180m36dBDIN55510
GangwayCR400AF/650mmR180m、R180m-10m-R180m38dBQ/CR699
FairingCRH3A/650mmR180m、R180m-10m-R180m/Q/CR699
GangwayCRH6one piece of side wallBelow500mm side wall 700mmR180m、R180m-10m-R180m36dBDIN55510
GangwayCR400AF/650mmR180m、R180m-10m-R180m38dBQ/CR699
GangwayCR400BF/650mmR180m、R180m-10m-R180m38dBQ/CR699
FairingCR400BF/650mmR180m、R180m-10m-R180m/Q/CR699
GangwayCRH6one piece of side wallBelow500mm side wall 700mmR180m、R180m-10m-R180m36dBDIN55510
GangwayCRH6one piece of side wallBelow500mm side wall 700mmR180m、R180m-10m-R180m36dBDIN55510
GangwayCR400BF/650mmR180m、R180m-10m-R180m38dBQ/CR699
GangwayCR400BF/650mmR180m、R180m-10m-R180m38dBQ/CR699
FairingCR400BF/650mmR180m、R180m-10m-R180m/Q/CR699
GangwayCR400BF/650mmR180m、R180m-10m-R180m38dBQ/CR699
FairingCR400BF/650mmR180m、R180m-10m-R180m/Q/CR699
GangwayCR400BF/650mmR180m、R180m-10m-R180m38dBQ/CR699
FairingCR400BF/650mmR180m、R180m-10m-R180m/Q/CR699
GangwayCR400BF/650mmR180m、R180m-10m-R180m38dBQ/CR699
FairingCR400BF/650mmR180m、R180m-10m-R180m/Q/CR699
FairingCR400AF/650mmR180m、R180m-10m-R180m/Q/CR699
GangwayCR400BF/650mmR180m、R180m-10m-R180m38dBQ/CR699
FairingCR400BF/650mmR180m、R180m-10m-R180m/Q/CR699
GangwayCR400AF/650mmR180m、R180m-10m-R180m38dBQ/CR699
GangwayCR400AF/650mmR180m、R180m-10m-R180m38dBQ/CR699
GangwayCR400BF/650mmR180m、R180m-10m-R180m38dBQ/CR699
FairingCR400BF/650mmR180m、R180m-10m-R180m/Q/CR699
GangwayCR400BF/650mmR180m、R180m-10m-R180m38dBQ/CR699
FairingCR400BF/650mmR180m、R180m-10m-R180m/Q/CR699
GangwayCR400AF/650mmR180m、R180m-10m-R180m38dBQ/CR699
FairingCR200J/800mmR145m、R145m-10m-R145m/TB3138
GangwayCR200J/800mmR145m、R145m-10m-R145m34dBTB3138
FairingCR400AF/650mmR180m、R180m-10m-R180m/Q/CR699
GangwayCR400AF/650mmR180m、R180m-10m-R180m38dBQ/CR699
GangwayCR400AF/650mmR180m、R180m-10m-R180m38dBQ/CR699
GangwayCR400AF/650mmR180m、R180m-10m-R180m38dBQ/CR699
Gangway//600mmR115、R100m-1m-R100m27dBEN45545 H.L2
GangwayCR400AF/650mmR180m、R180m-10m-R180m36dBQ/CR699
FairingCR400AF/650mmR180m、R180m-10m-R180m/Q/CR699
GangwayCR400AF/650mmR180m、R180m-10m-R180m38dBQ/CR699
FairingCR400AF/650mmR180m、R180m-10m-R180m/Q/CR699
GangwayCRH6Fone piece of side wallBelow500mm side wall 700mmR180m、R180m-10m-R180m36dBDIN55510
GangwayCR400AF/650mmR180m、R180m-10m-R180m40dBQ/CR699
GangwayCRH6Fone piece of side wallBelow500mm side wall 700mmR180m、R180m-10m-R180m36dBDIN55510
GangwayCRH6Fone piece of side wallBelow500mm side wall 700mmR180m、R180m-10m-R180m36dBDIN55510
GangwayCRH6Aone piece of side wallBelow500mm side wall 700mmR180m、R180m-10m-R180m36dBDIN55510
GangwayCR400AF/650mmR180m、R180m-10m-R180m36dBQ/CR699
GangwayCR400BF/650mmR180m、R180m-10m-R180m38dBQ/CR699
FairingCR400BF/650mmR180m、R180m-10m-R180m/Q/CR699
GangwayCR400BF/650mmR180m、R180m-10m-R180m38dBQ/CR699
FairingCR400BF/650mmR180m、R180m-10m-R180m/Q/CR699
GangwayCR400BF/650mmR180m、R180m-10m-R180m38dBQ/CR699
GangwayCR400AF/650mmR180m、R180m-10m-R180m38dBQ/CR699
GangwayCR400AF/650mmR180m、R180m-10m-R180m38dBQ/CR699
GangwayCR400BF/650mmR180m、R180m-10m-R180m38dBQ/CR699
FairingCR400BF/650mmR180m、R180m-10m-R180m/Q/CR699
GangwayCR400AF/650mmR180m、R180m-10m-R180m36dBQ/CR699
GangwayCR400BF/650mmR180m、R180m-10m-R180m38dBQ/CR699
FairingCR400BF/650mmR180m、R180m-10m-R180m/Q/CR699
FairingCR400BF/650mmR180m、R180m-10m-R180m/Q/CR699
FairingCR400BF/650mmR180m、R180m-10m-R180m/Q/CR699
FairingCR400AF/650mmR180m、R180m-10m-R180m/Q/CR699
Gangway//500mmR76m、R120m-0m-R120m35dBKorean standard
Gangway//746mmR100m(3.9°+3.9°)、S150m35dBEN45545 HL2
GangwayCRH6Aone piece of side wallBelow500mm side wall 700mmR180m、R180m-10m-R180m36dBDIN55510
GangwayCR300AF/650mmR180m、R180m-10m-R180m38dBQ/CR699
GangwayCR300AF/650mmR180m、R180m-10m-R180m38dBQ/CR699
GangwayCR300BF/650mmR180m、R180m-10m-R180m38dBQ/CR699
FairingCR300BF/650mmR180m、R180m-10m-R180m/Q/CR699
GangwayCR300BF/650mmR180m、R180m-10m-R180m38dBQ/CR699
FairingCR300BF/650mmR180m、R180m-10m-R180m/Q/CR699
GangwayCR400AF/650mmR180m、R180m-10m-R180m38dBQ/CR699
GangwayCR300AF/650mmR180m、R180m-10m-R180m38dBQ/CR699
GangwayCR300AF/650mmR180m、R180m-10m-R180m38dBQ/CR699
GangwayCR300AF/650mmR180m、R180m-10m-R180m38dBQ/CR699
FairingCR300AF/650mmR180m、R180m-10m-R180m/Q/CR699
FairingCR200J/800mmR145m、R145m-10m-R145m/Q/CR699
GangwayCR200J/800mmR145m、R145m-10m-R145m34dBQ/CR699
GangwayCR400BF/650mmR180m、R180m-10m-R180m38dBQ/CR699
FairingCR400BF/650mmR180m、R180m-10m-R180m/Q/CR699
Gangway//737mmR300m/EN45545-2
FairingCR300AF/650mmR180m、R180m-10m-R180m/Q/CR699
GangwayCR300AF/650mmR180m、R180m-10m-R180m38dBQ/CR699
GangwayCR300AF/650mmR180m、R180m-10m-R180m38dBQ/CR699
FairingCR300AF/650mmR180m、R180m-10m-R180m/Q/CR699
GangwayCR200J/800mmR145m、R145m-10m-R145m34dBQ/CR699
GangwayCR200J/800mmR145m、R145m-10m-R145m34dBQ/CR699
GangwayCR200J/800mmR145m、R145m-10m-R145m34dBQ/CR699
GangwayCR200J/800mmR145m、R145m-10m-R145m34dBQ/CR699
FairingCR200J/800mmR145m、R145m-10m-R145m/Q/CR699
GangwayCR200J/800mmR145m、R145m-10m-R145m34dBQ/CR699
FairingCR200J/800mmR145m、R145m-10m-R145m/Q/CR699
GangwayCR400AF/650mmR180m、R180m-10m-R180m38dBQ/CR699
GangwayCR400AF/650mmR180m、R180m-10m-R180m38dBQ/CR699
GangwayCR400AF/650mmR180m、R180m-10m-R180m38dBQ/CR699
Gangway//746mmR100m(3.9°+3.9°)、S150m35dBEN45545 HL2
GangwayCR200J/800mmR145m、R145m-10m-R145m34dBQ/CR699
GangwayCR200J/800mmR145m、R145m-10m-R145m34dBQ/CR699
GangwayCRH5A-A/650mmR180m、R180m-10m-R180m38dBQ/CR699
Fairing//920mmR100m/EN45545 HL2
GangwayCR400AF/650mmR180m、R180m-10m-R180m38dBQ/CR699
GangwayCR400BF/650mmR180m、R180m-10m-R180m38dBQ/CR699
FairingCR400BF/650mmR180m、R180m-10m-R180m/Q/CR699
GangwayCR400BF/650mmR180m、R180m-10m-R180m38dBQ/CR699
FairingCR400BF/650mm
GangwayCR400BF/650mmR180m、R180m-10m-R180m38dBQ/CR699
FairingCR400BF/650mmR180m、R180m-10m-R180m38dBQ/CR699
GangwayCR400BF/650mmR180m、R180m-10m-R180m38dBQ/CR699
FairingCR400BF/650mmR180m、R180m-10m-R180m/Q/CR699
GangwayCR400BF/650mmR180m、R180m-10m-R180m38dBQ/CR699
FairingCR400BF/650mmR180m、R180m-10m-R180m/Q/CR699
GangwayCR200J/800mmR145m、R145m-10m-R145m34dBQ/CR699
FairingCR200J/800mmR145m、R145m-10m-R145m/Q/CR699
GangwayHXD1/340mmR125m、R145m-0m-R145m/DIN55510
GangwayCR200J/800mmR145m、R145m-10m-R145m34dBQ/CR699
GangwayCR200J/800mmR145m、R145m-10m-R145m34dBQ/CR699
GangwayCR400AF/650mmR180m、R180m-10m-R180m38dBQ/CR699
FairingCR400AF/650mmR180m、R180m-10m-R180m/Q/CR699
GangwayCR400AF/650mmR180m、R180m-10m-R180m38dBQ/CR699
GangwayCR400AF/650mmR180m、R180m-10m-R180m38dBQ/CR699
GangwayCR200J/800mmR145m、R145m-10m-R145m34dBQ/CR699
GangwayCR400BF/650mmR180m、R180m-10m-R180m38dBQ/CR699
FairingCR400BF/650mmR180m、R180m-10m-R180m/Q/CR699
GangwayCR400AF/650mmR180m、R180m-10m-R180m38dBQ/CR699
GangwayCRH6one piece of side wallBelow500mm side wall 700mmR180m、R180m-10m-R180m40dBQ/CR699
GangwayCR200J/800mmR145m、R145m-10m-R145m34dBQ/CR699
GangwayCR200J/800mmR145m、R145m-10m-R145m34dBQ/CR699
FairingCR200J/800mmR145m、R145m-10m-R145m/Q/CR699
Gangway//900mmR65m、R90m-0m-R90m30dBEN45545 HL2
Gangway25T/800mmR145m、R145m-10m-R145m26dBQ/CR699
GangwayCR200J/800mmR145m、R145m-10m-R145m34dBQ/CR699
GangwayCR400BF/650mmR180m、R180m-10m-R180m40dBQ/CR699
FairingCR400BF/650mmR180m、R180m-10m-R180m/Q/CR699
GangwayCR400BF/650mmR180m、R180m-10m-R180m38dBQ/CR699
FairingCR400BF/650mmR180m、R180m-10m-R180m/Q/CR699
GangwayCR400AF/650mmR180m、R180m-10m-R180m38dBQ/CR699
GangwayCR400AF/650mmR180m、R180m-10m-R180m38dBQ/CR699
FairingCR400AF/650mmR180m、R180m-10m-R180m/Q/CR699
GangwayCRH6one piece of side wallBelow500mm side wall 700mmR180m、R180m-10m-R180m36dBDIN55510
GangwayCR200J/800mmR145m、R145m-10m-R145m34dBQ/CR699
GangwayCR200J/800mmR145m、R145m-10m-R145m34dBQ/CR699
FairingCR200J/800mmR145m、R145m-10m-R145m/Q/CR699
GangwayFXD2B/400mmR125m、R180m-10m-R180m34dBEN45545
GangwayCR200J/800mmR145m、R145m-10m-R145m34dBQ/CR699
GangwayCR200J/800mmR145m、R145m-10m-R145m34dBQ/CR699
GangwayCR200J/800mmR145m、R145m-10m-R145m34dBQ/CR699
GangwayCR400AF/650mmR180m、R180m-10m-R180m38dBQ/CR699
FairingCR400AF/650mmR180m、R180m-10m-R180m/Q/CR699
GangwayCR400BF/650mmR180m、R180m-10m-R180m38dBQ/CR699
FairingCR400BF/650mmR180m、R180m-10m-R180m/Q/CR699
GangwayCR400BF/650mmR180m、R180m-10m-R180m38dBQ/CR699
FairingCR400BF/650mmR180m、R180m-10m-R180m/Q/CR699
GangwayCRH6one piece of side wallBelow500mm side wall 700mmR180m、R180m-10m-R180m40dBQ/CR699
FairingCR200J/800mmR145m、R145m-10m-R145m/Q/CR699
GangwayCR400BF/650mmR180m、R180m-10m-R180m40dBEN45545 HL2
FairingCR400BF/650mmR180m、R180m-10m-R180m/Q/CR699
Gangway//666mmR120m、S170m-0m-S170m30dBEN45545 HL2
GangwayCR400BF/650mmR180m、R180m-10m-R180m40dBEN45545 HL2
FairingCR400BF/650mmR180m、R180m-10m-R180m/Q/CR699
GangwayCR400BF/650mmR180m、R180m-10m-R180m40dBEN45545 HL2
FairingCR400BF/650mmR180m、R180m-10m-R180m/Q/CR699
GangwayCR400AF/650mmR180m、R180m-10m-R180m40dBEN45545 HL2
GangwayCR400AF/650mmR180m、R180m-10m-R180m40dBEN45545 HL2
GangwayCR400AF/650mmR180m、R180m-10m-R180m40dBEN45545 HL2
FairingCR400AF/650mmR180m、R180m-10m-R180m/Q/CR699
GangwayCR450/650mmR180m、R180m-10m-R180m40dBEN45545 HL2
FairingCR450/650mmR180m、R180m-10m-R180m/EN45545 HL2
GangwayCR400AF/650mmR180m、R180m-10m-R180m40dBEN45545 HL2
GangwayCR450/650mmR180m、R180m-10m-R180m40dBEN45545 HL2
FairingCR450/650mmR180m、R180m-10m-R180m26dBEN45545 HL2
——END——

Coming soon

Coming soon…

Note: All Above Data are Just for Reference, All Data Might Change Without Notices or Updates, Please Contact Our Sales Team to Confirm All Details Via WhatsApp or Email.

The picture of Sale Manual showing the accessories and scopes of supply.

Engine Sale Manual

The picture of Installation Drawing showing the accessories and scopes of supply.

Installation Drawing

The picture of Installation Manual showing the accessories and scopes of supply.

Installation Manual

The picture of Operation Manual showing the accessories and scopes of supply.

Operation Manual

The picture of Engine Parts Catalogue showing the accessories and scopes of supply.

Parts Catalogue

The picture of Test Report and Certifcate showing the accessories and scopes of supply.

Report & Certifcate

Global Activity

WhatsApp Online logo

Sales Team


RailMac Manager-Mr.LeoWhatApp-Icon

RailMac Assistant-Ms.CathyWhatApp-Icon

Generator-SinoGenWhatApp-Icon

EV System-EVMacWhatApp-Icon


Sales Manager-Mrs.Wendy FuWhatApp-Icon

Sales Director-Mr.Jasper Lee WhatApp-Icon

Shipping ServiceWhatApp-Icon

Contact EMAC Now!

Subscribe To Our Newsletter

Subscribe to get the latest updates from www.train.parts

Welcome on board, we will keep you updated with latest news and business activities!

Pin It on Pinterest
