Pantograph Test Bench
In the electrified railway domain, a Pantograph Test Bench plays a pivotal role in ensuring the reliable operation of the power collection system. This specialized equipment is designed to comprehensively assess the performance of pantographs, which are crucial components for trains to draw electrical power from overhead catenary systems.
Advantages of Pantograph Test Bench
- Simulate Multiple Operating Conditions: It can simulate the working states of the pantograph under different operating speeds (covering various conditions such as low speed, medium speed, and high speed), different line conditions (such as different catenary heights and tension changes), and different climatic environments (such as harsh weather conditions like strong winds, rain, and snow). By comprehensively simulating these complex conditions, it can fully test the adaptability, reliability, and safety of the pantograph, discover potential problems in advance, provide a strong basis for the optimized design and maintenance of the pantograph, and ensure that it can work properly in various actual operating scenarios.
Features of Pantograph Test Bench
- Intelligent Data Analysis: It is equipped with an intelligent data analysis system that can deeply mine and analyze a large amount of pantograph test data collected. Through data analysis, intuitive charts and reports can be generated to display information such as the performance change trends of the pantograph and fault probability analysis. At the same time, by using machine learning algorithms to learn and train historical data, it can predict the potential faults and performance degradation of the pantograph, provide a scientific basis for preventive maintenance, and realize the intelligent management and maintenance of the pantograph.
RMSW-75B | HXD2/HXD2B
RMSW-75B pneumatic wiper is suitable for HXD2 and HXD2B locomotives. It is specially designed for high-speed trains and heavy-load locomotives. It has strong wiper ability and reliable performance. In severe weather conditions such as heavy rain, heavy snow, and hail, it can keep the front window of the train clear, ensure the driver’s good vision, and ensure driving safety.
Tourist Train
The CRRC Zhuzhou 1435 series dual rail sightseeing car inherits the technological DNA of CRRC high-speed rail and is designed for in-depth sightseeing in scenic areas. The innovative double-decker structure features a panoramic window on the first floor for comfortable all-weather sightseeing and an open-top layout on the second floor for a 360° immersive natural experience.
Traction System
CHSR's CHSR™ CC750 air-cooled converter is a highly integrated traction and auxiliary "two-in-one" core equipment. It condenses key power conversion functions into a single compact enclosure, providing robust and stable power for intercity trains through standardized modular design, intelligent air cooling (IP65 protection), and mature and reliable components.
Bogie and Braking System
CRRC Braking Systems Co., Ltd.'s disc brake calipers use hydraulic or pneumatic-hydraulic conversion drive technology.They integrate automatic gap adjustment, modular caliper body, and three-point floating suspension design to ensure precise contact between brake pads and discs.
Track Body Components
RailMac provides railway solutions, focusing on one-stop Lince/Huanji wiper services (R&D, production, maintenance) plus rail air conditioning. It offers diverse wipers (DC110V/74V/24V, pneumatic) and developed China’s first IP-owned CRH3 EMU wiper, with products batch-loaded in CRH380/CR400BF/CR300BF.
Maintenance Equipment
RunWell is a high-tech enterprise specializing in the fields of rail transit and military industry. Its car lift machine products integrate German drive technology (such as the Demag three-in-one modular system) with intelligent control, supporting heavy-duty conditions of over 150 tons.
Railway Components
CRRC specializes in innovative environmental protection sanitation systems. Products like vacuum water - saving toilet modules and waterless ecological toilets, made in an orderly factory, are applied in railways, public facilities, and outdoor scenarios.
RailMac
Partnering with global leaders, RailMac offers superior railway equipment and solutions at competitive prices. It hit milestones like Thailand’s 2017 first local train, pioneered SEA new energy trains, and joined Russia’s high-speed rail project, boosting its railway industry presence.
General Specifications of Pantograph Test Bench
| Height measurement | Pressure measurement | Lifting bow time detection resolution | Air pressure adjustment | Time measurement | Lifting bow time detection resolution |
| mm | N | s | MPa | s | s |
| 0～3000 mm | 0～300 N | 0.1 s | 0.05～1.0 MPa | 0～99.9 s | 0.1 s |
