Bogie Training System
Bogie training system adopts HX series bogie, mainly consists of intelligent training management system, intelligent tool cabinet, torque management system, bogie, rail bridge, maintenance trench, etc. The platform is embedded with expert guidance and intelligent scoring function, which supports three modes of learning, practicing, and examining, and is able to satisfy the teaching and training of such functions as component replacement, size measurement, structural cognition, principle, and pressure preservation test.
Advantages of Bogie Training System
- Realistic Bogie Simulation Model: The Bogie Training System is equipped with a highly simulated bogie model. Whether it is the mechanical structure, appearance size, or the material and performance of key components, it is highly consistent with the actual bogie. Trainees can intuitively observe the real structure of each part of the bogie, such as the frame, wheel – set, suspension device, and traction device. By personally touching and operating the simulation model, trainees can deeply understand the connection methods, relative motion relationships, and working principles among the various components of the bogie. For example, trainees can simulate the installation and disassembly process of the wheel – set,
Features of Bogie Training System
- Interactive Teaching Experience: It adopts an interactive teaching mode, which greatly improves the learning enthusiasm and participation of trainees. Trainees can interact with the training system in real – time through operating consoles, touch – screen devices, etc., and independently control the operation and changes of the simulated scenarios.
Vehicle Auxiliary Power System-Video-DB2/3 | CR300BF/CR400BF
Vehicle Auxiliary Power System-Video-DB2/3 wiper device is CR300BF, CR400BF standard EMU supporting product produced for CRRC Tangshan Company and Changke Corporation. The wiper system is composed of the following components: a drive device, a scraper arm, a scraper frame, a scraper, a pump, a liquid level display switch, a junction box and a wiper switch. Among them, the core component of the wiper motor has been implemented domestically.
Tourist Train
The CRRC Zhuzhou 1435 series dual rail sightseeing car inherits the technological DNA of CRRC high-speed rail and is designed for in-depth sightseeing in scenic areas. The innovative double-decker structure features a panoramic window on the first floor for comfortable all-weather sightseeing and an open-top layout on the second floor for a 360° immersive natural experience.
Traction System
CHSR's CHSR™ CC750 air-cooled converter is a highly integrated traction and auxiliary "two-in-one" core equipment. It condenses key power conversion functions into a single compact enclosure, providing robust and stable power for intercity trains through standardized modular design, intelligent air cooling (IP65 protection), and mature and reliable components.
Bogie and Braking System
CRRC Braking Systems Co., Ltd.'s disc brake calipers use hydraulic or pneumatic-hydraulic conversion drive technology.They integrate automatic gap adjustment, modular caliper body, and three-point floating suspension design to ensure precise contact between brake pads and discs.
Track Body Components
RailMac provides railway solutions, focusing on one-stop Lince/Huanji wiper services (R&D, production, maintenance) plus rail air conditioning. It offers diverse wipers (DC110V/74V/24V, pneumatic) and developed China’s first IP-owned CRH3 EMU wiper, with products batch-loaded in CRH380/CR400BF/CR300BF.
Maintenance Equipment
RunWell is a high-tech enterprise specializing in the fields of rail transit and military industry. Its car lift machine products integrate German drive technology (such as the Demag three-in-one modular system) with intelligent control, supporting heavy-duty conditions of over 150 tons.
Railway Components
CRRC specializes in innovative environmental protection sanitation systems. Products like vacuum water - saving toilet modules and waterless ecological toilets, made in an orderly factory, are applied in railways, public facilities, and outdoor scenarios.
RailMac
Partnering with global leaders, RailMac offers superior railway equipment and solutions at competitive prices. It hit milestones like Thailand’s 2017 first local train, pioneered SEA new energy trains, and joined Russia’s high-speed rail project, boosting its railway industry presence.
General Specifications of Bogie Training System
No available data at the moment
