Air Compressor Test Bench
Air compressor test bench can be used for the performance test of air compressor after overhauling, including exhaust gas volume test, exhaust gas temperature measurement, as well as current, voltage and power test, overload test, leakage test and other test items.
Advantages of Air Compressor Test Bench
- Precise Performance Evaluation: With the help of high – precision pressure sensors, flow sensors and other equipment, it can accurately measure key performance indicators such as discharge pressure, flow rate, and power consumption of the air compressor under different working conditions. The error can be controlled within a very small range, providing a reliable basis for product quality control and performance optimization.
- Simulate Diverse Working Conditions: It can simulate complex working conditions in a variety of practical application scenarios, such as air pressure environments at different altitudes, different temperature conditions, and frequent start – stop. It comprehensively tests the operation stability and reliability of the air compressor under various extreme and normal working conditions, ensuring that the product can meet various challenges in actual use.
Features of Air Compressor Test Bench
- Simple and Intuitive Operation: It is equipped with a simple and easy – to – understand human – machine interaction interface. Operators can easily complete operations such as parameter setting, test start and stop through graphical menus. At the same time, real – time data is displayed in the form of intuitive charts, making it easy to quickly understand the test progress and results.
Vehicle Auxiliary Power System-Video-AH5/AH5-1 | HXN5/HXN5B
Vehicle Auxiliary Power System-Video-AH5 and Vehicle Auxiliary Power System-Video-AH5-1 electric wipers are suitable for HXN5 modification and installation. Each vehicle’s wiper system consists of 2 sets of door wipers and 2 sets of window wipers.
Tourist Train
The CRRC Zhuzhou 1435 series dual rail sightseeing car inherits the technological DNA of CRRC high-speed rail and is designed for in-depth sightseeing in scenic areas. The innovative double-decker structure features a panoramic window on the first floor for comfortable all-weather sightseeing and an open-top layout on the second floor for a 360° immersive natural experience.
Traction System
CHSR's CHSR™ CC750 air-cooled converter is a highly integrated traction and auxiliary "two-in-one" core equipment. It condenses key power conversion functions into a single compact enclosure, providing robust and stable power for intercity trains through standardized modular design, intelligent air cooling (IP65 protection), and mature and reliable components.
Bogie and Braking System
CRRC Braking Systems Co., Ltd.'s disc brake calipers use hydraulic or pneumatic-hydraulic conversion drive technology.They integrate automatic gap adjustment, modular caliper body, and three-point floating suspension design to ensure precise contact between brake pads and discs.
Track Body Components
RailMac provides railway solutions, focusing on one-stop Lince/Huanji wiper services (R&D, production, maintenance) plus rail air conditioning. It offers diverse wipers (DC110V/74V/24V, pneumatic) and developed China’s first IP-owned CRH3 EMU wiper, with products batch-loaded in CRH380/CR400BF/CR300BF.
Maintenance Equipment
RunWell is a high-tech enterprise specializing in the fields of rail transit and military industry. Its car lift machine products integrate German drive technology (such as the Demag three-in-one modular system) with intelligent control, supporting heavy-duty conditions of over 150 tons.
Railway Components
CRRC specializes in innovative environmental protection sanitation systems. Products like vacuum water - saving toilet modules and waterless ecological toilets, made in an orderly factory, are applied in railways, public facilities, and outdoor scenarios.
RailMac
Partnering with global leaders, RailMac offers superior railway equipment and solutions at competitive prices. It hit milestones like Thailand’s 2017 first local train, pioneered SEA new energy trains, and joined Russia’s high-speed rail project, boosting its railway industry presence.
General Specifications of Air Compressor Test Bench
| Air compressor power | Ambient temperature | Ambient humidity | Atmospheric pressure | Cylinder pressure | Flow rate | Differential pressure detection | Inlet temperature | Outlet temperature | Outlet pressure | Primary exhaust temperature | Secondary exhaust temperature | Air compressor speed |
| V / kw | ℃ | % | kPa | kPa | m³/min | kPa | ℃ | ℃ | ℃ | ℃ | ℃ | r/min |
| AC0-600V 0-50A | -20～50 ℃ | 0～95% RH | 0～110kPa | 0～1600kPa | 0.3～3.0 m³/min | 1～10 kPa | -40～350 ℃ | -40～350 ℃ | -40～350 ℃ | -40～350 ℃ | -40～350 ℃ | 0～3000 r/min |
| ——END—— | ||||||||||||
