RailMac On-board Self-contained Auxiliary Power Supply System
Auxiliary power supply: meet the auxiliary power supply needs of emergency ventilation, lighting, communication control, etc.;
Mainline self-traction: realize the emergency self-traction of vehicles under the mainline A W 3 load;
In-depot self-traction: realize in-depot shunting, track switching, non-electric car washing and other operations;
Features of On-board Self-contained Auxiliary Power Supply System
Lightweight: Compared with traditional battery systems with the same capacity, the weight is reduced by more than 40% and the volume is reduced by more than 20%;
High power: The high-rate charging and discharging capability is strong, meeting the requirements of vehicle self-traction on steep slope lines;
Informatization: Equipped with a battery management system to achieve online detection, control and protection of the battery system;
Long life: The service life reaches more than 15 years;
Maintenance-free: The maintenance workload is reduced by more than 90% compared with traditional batteries;
Internationally advanced: The key technology of vehicle auxiliary power supply and emergency self-traction integration has been evaluated as “Internationally Advanced” scientific and technological achievements by the Rail Transit Association;
High safety: The battery has undergone needle puncture, extrusion and cutting experiments, and the product does not smoke, catch fire or explode; The product has obtained third-party safety assessment certification based on SIL2 and IEC62928;
Vehicle On-board Self-contained Auxiliary Power Supply System technical parameter table
| Battery type: | Lithium titanate battery |
| Quantity: | 2 Boxes / Row |
| Rated capacity: | 315Ah / Box |
| Battery pack rated voltage: | 103.5 V |
| Voltage usage range: | 77V ~ 124V |
| Rated capacity: | 32.6kWh / Box |
| Continuous output power: | 160kW / Box |
| Cooling method: | Natural Heat Dissipation |
| Applicable ambient temperature: | -40℃ ~ 55℃ |
| Communication method: | Ethernet |
| Weight: | 1300kg / Box |
| Dimensions (L * W * H): | 2100 mm * 1803 mm * 639 mm |
| Protection level: | IP65 |
