RailMac Lifting Jack
RunWell is a high-tech enterprise specializing in the fields of rail transit and military industry. Its car lift machine products integrate German drive technology (such as the Demag three-in-one modular system) with intelligent control, supporting heavy-duty conditions of over 150 tons. The company has innovatively developed a patented technology — the online pressing and positioning trolley. By using spring buffering and V-shaped slide rail structure, it enhances the stability of operations. Moreover, it integrates an intelligent vehicle relocation path planning system and a tilting test platform, achieving efficient and precise maintenance and inspection of heavy-duty equipment.
Advantages of Rail Lifting Jack Series
RunWell’s rail transit Lifting Jack is a high-performance, heavy-duty solution designed for demanding rail and military applications. Utilizing advanced German drive technology and intelligent control algorithms, it ensures stability under loads exceeding 150 tons. The system incorporates a patented online pressing and positioning trolley with spring buffering and a V-shaped slide rail to reduce vibration and improve accuracy. An intelligent path planning system optimizes workflow, while a built-in tilting test platform enables efficient maintenance. Combining robust capacity with smart technology, it delivers an efficient and reliable solution for heavy rail maintenance.
General Specifications of Lifting Jack Series
| Three-phase power supply: | AC 220V±10% 60Hz (compatible with Zaragoza workshop power plugs) |
| Lifting capacity of a single mobile jacking machine: | ≥ 25t |
| Lifting capacity of a 4-unit mobile jacking machine set: | ≥ 100t |
| Lifting/lowering speed: | approx. 240mm/min |
| Height of the bracket (lowest position, above rail top): | ≤700mm (to be confirmed at the design liaison stage) |
| Vertical stroke of the bracket: | ≥1600mm |
| Driving power of each mobile jacking machine: | ≤4kW |
Vehicle Auxiliary Power System-Video-DB2/3 | CR300BF/CR400BF
Vehicle Auxiliary Power System-Video-DB2/3 wiper device is CR300BF, CR400BF standard EMU supporting product produced for CRRC Tangshan Company and Changke Corporation. The wiper system is composed of the following components: a drive device, a scraper arm, a scraper frame, a scraper, a pump, a liquid level display switch, a junction box and a wiper switch. Among them, the core component of the wiper motor has been implemented domestically.
Tourist Train
The CRRC Zhuzhou 1435 series dual rail sightseeing car inherits the technological DNA of CRRC high-speed rail and is designed for in-depth sightseeing in scenic areas. The innovative double-decker structure features a panoramic window on the first floor for comfortable all-weather sightseeing and an open-top layout on the second floor for a 360° immersive natural experience.
Traction System
CHSR's CHSR™ CC750 air-cooled converter is a highly integrated traction and auxiliary "two-in-one" core equipment. It condenses key power conversion functions into a single compact enclosure, providing robust and stable power for intercity trains through standardized modular design, intelligent air cooling (IP65 protection), and mature and reliable components.
Bogie and Braking System
CRRC Braking Systems Co., Ltd.'s disc brake calipers use hydraulic or pneumatic-hydraulic conversion drive technology.They integrate automatic gap adjustment, modular caliper body, and three-point floating suspension design to ensure precise contact between brake pads and discs.
Track Body Components
RailMac provides railway solutions, focusing on one-stop Lince/Huanji wiper services (R&D, production, maintenance) plus rail air conditioning. It offers diverse wipers (DC110V/74V/24V, pneumatic) and developed China’s first IP-owned CRH3 EMU wiper, with products batch-loaded in CRH380/CR400BF/CR300BF.
Maintenance Equipment
RunWell is a high-tech enterprise specializing in the fields of rail transit and military industry. Its car lift machine products integrate German drive technology (such as the Demag three-in-one modular system) with intelligent control, supporting heavy-duty conditions of over 150 tons.
Railway Components
CRRC specializes in innovative environmental protection sanitation systems. Products like vacuum water - saving toilet modules and waterless ecological toilets, made in an orderly factory, are applied in railways, public facilities, and outdoor scenarios.
RailMac
Partnering with global leaders, RailMac offers superior railway equipment and solutions at competitive prices. It hit milestones like Thailand’s 2017 first local train, pioneered SEA new energy trains, and joined Russia’s high-speed rail project, boosting its railway industry presence.
RailMac Lifting Jack Series
This is the list of all series of RailMac Lifting Jack.
Click here to find lifting jack by type
Products Not Available
The relevant products still under developing or waiting to be update, please contact our sales team for latest updates.
